AutoCAD 2015 LT Reference Lines

by Anonymous
(Wentzville, Missouri, United States)

AutoCAD 2015 LT Reference Lines

AutoCAD 2015 LT Reference Lines

I am pretty much a rookie to all of the awesome things you can do with AutoCAD, but I can get around for what I use it for.

I bought 2015LT and some how turned on without realizing it what appears to be reference lines of sort.

They can't be selected and I can't figure out how to get them turned off. It is not individual drawing specific.

Please see the attached screen shot. Any help would be great!

Click here to post comments
